CRF1100L PC-8 50A Accessory Fuse Box
Table of Contents
PC-8 Specifications and Features:
– Uses no power when the ignition is off.
– 4 threaded insert nuts provide case mounting and fuse panel installation mounting points.
– comes with an assortment of ATM fuses, one for each output circuit and a few extras
– 8 hot + outputs (2 unswitched circuits, 6 switched circuits).
– Switched circuits turn off when the bike is off. An unswitched circuit is always hot – can be used for charging the battery.
– 8 ground outputs – much better to ground your auxiliary circuits here than on a bike’s frame.
– maximum fuse panel capacity 50 Amps (30A/20A – switched/unswitched).
– maximum circuit capacity 20 Amps (15A continuous).
– maximum output wire size 12 AWG (3 sqmm).
– all hardware is stainless steel (except input posts which are tin plated steel)
– black satin polycarbonate cover makes unit splash-proof yet allows it to breathe and stay cool
– cover mounting tabs on each end can be broken off or left on, depending on mounting choice.
– simple robust design means no overheating and no problems with vibration.
– I designed this fuse panel with ease of mounting a priority. Therefore there are many mounting options: Dual Lock on back of case, fine threaded screws from back of panel, self tapping screws from inside through PCB inserts to panel, or nuts and screws on the case mounting ears at each end of the case.
Complete plug and play kits, with all the wiring, a 50A relay, fuses, a PC-8 fuse panel, and more. This superb fuse panel is full of all the features every rider has ever wanted and more! Easy to install, well protected, and with 8 mini fuses, one on each output circuit. Includes 8 output grounds too. Kit is made from highest quality high temp wire and sheathing. This Kit is custom made for the new Africa Twin and is plug and play. Everything you need is included. Just strip your circuit wires and insert into the PC-8 outputs and tighten the screws. Both power and ground terminal blocks are built in. This Kit is now 50A capable using dual main fuse holders. The black fuse holder (30A max) serves 6 switched circuits, the white fuse holder (20A max) serves the 2 unswitched circuits.
Please Note – all CRF1100 PC8 and 4CS Kits now use the plate light connector found at rear left under pillion seat. A longer kit is available to mount the PC-8 under the pillion seat area.
CRF1100L PC-8 Fuse Box Kit
Accessory fuse box for the CRF1100L. 50Amp rated. 6 switched and 2 battery direct connections. Simple plug and play installation. Uses the plate light connector for switched power. The PowerLink version provides a PowerLink ( high power ) connection under the seat for jump starting & easy disconnection of all accessories ( if Battey is weak for starting ).
CRF1100L PC-8 – [Wiring Kit Only]
Plug & Play wiring kit for the PC-8. For those moving a PC-8 from their old bike to a Honda CRF1100L. Saves you having to purchase another PC-8 unit. A great feature of the PC-8 is that it is built to last, and is easily moved from one bike to another by purchasing the wiring kit for your new bike.
Dual Lock Super Stong Velcro 2 Pieces
Super strong 3M dual lock velcro. Clean surfaces before installing. Great for fixing the PC-8 or PC-8R to plastic surfaces.
SAE Cable – 16 AWG Stripped Ends to SAE
SAE to bare wire ends. 72″ or 1.8m long. 16AWG lead length. Can be connected to the PC-8 or PC-8R for battery charger or heated gear connections.
This Kit is custom made for the new Africa Twin and is plug and play. Everything you need is included. Just strip your circuit wires and insert into the PC-8 outputs and tighten the screws. Both power and ground terminal blocks are built in.
To install this Kit you need to remove the left side tank side trim, and pull the battery out half way. Wires are easy to route to the battery and when you’re finished, everything will look built into the bike. You should be able to locate the PC-8 just about anywhere under the seat. Install the main fuses after complete installation. A longer kit is available to mount the PC-8 in the far back of the under seat area. It is 8 inches longer than the regular Kit.
