Wiring Tools
Table of Contents
Hand Held Crimpers
Hozan P-706 Crimper
Hozan P-706 Crimping Tool
FEATURES:
– multiple crimp dies for many sizes of popular small open barrel terminals
– also crimps over wire seal wings (this is the best crimper I have for sealed types)
– high quality, made in Japan tool
This tool will crimp all small type of open barrel terminals using wire up to about 16 AWG or 1.25 sqmm. It will not crimp the larger .250” Amp terminals I sell. It will crimp the terminals on all of my sealed connectors. It will also do wire insulation in the dies shown on the right above.
Hozan P-707 Crimper
Hozan P-707 Crimping Tool
We love this little crimper, it does an excellent job on wire up to 2 sqmm (14 AWG).
Non- ratcheting so you can easily apply just the right amount of pressure.
Die width varies, narrow for small wires, wider for larger wires.
Also works very well for most sealed types too! This is the most versatile crimper I sell. You won’t be disappointed with this little jewel.
Hero B-14 Crimper / Cutter / Stripper
Hero B-14 Crimper/Cutter/Stripper
Universal crimper, cutter and stripper. Works well at each task. Up t0 10AWG wires can be crimped. Excellent for 250, 110 and 090 terminals. Not suited to sealed terminals.
FEATURES:
– crimp wire sizes up to 5.5 sqmm (10 AWG) with open barrel terminals – not for sealed connectors.
– also cuts and strips wire – actually does a good job too!
– very versatile crimper for many different terminals
– high quality, made in Japan tool.
Hero BL-255 Crimper
Hero BL-255 Open Barrel Crimper
Universal crimper, cutter and stripper. Works well at each task. Up t0 10AWG wires can be crimped. Excellent for 250, 110 and 090 terminals. Not suited to sealed terminals.
FEATURES:
– crimps those thick brass hard to crimp battery terminals and more.
– ratchet release system releases when proper crimp is achieved.
– long handles make easy work of crimping tough terminals.
– flared die edges automatically bevel the edge of the wire crimp.
– crimps wire sizes from 1.25 to 3 sq mm (16-12 AWG).
– can also crimp multiple wires and larger wires by releasing the ratchet.
– high quality, heavy duty made in Japan tool.
– also crimps some Metripack terminals on 14 or 12 AWG wire.
NOT for .250” Amp terminals.
Terminal Extraction Tools
Hero FR-150 Terminal Extraction Tool Set
The FR-150 is effective for terminals, on wires up to about 2mm². The tool shaft material combines wear resistance and improved elasticity to further improve work efficiency, and the tip has a unique shape devised on the experience cultivated over many years as a manufacturer specializing in automotive repair parts. This allows for smooth and reliable extraction of terminals, and has earned the trust of on-site professionals involved in automotive maintenance for over a quarter of a century.
Metri-Pack Terminal Removal Tool
Terminal removal tool for Metri-Pack series connectors. Works on 280, 480, 630 and 56 series connectors.
Anti Static Products
Hozan F-14 Anti-Static Flexible Parts Tray
Hozan F-14 ESD ( Anti Static ) flexible and durable, parts trays. Very useful for weighting components ( counting ). Also useful for storing spare parts & connectors when working on specific jobs.
