KTM Adventure 1290 ( 2023+ )
Table of Contents
Specifications and Features:
- 4 threaded insert nuts provide case mounting and fuse panel installation mounting points
- comes with an assortment of ATM fuses, one for each output circuit and a few extras
- 8 hot + outputs (2 un-switched circuits, 6 switched circuits)
- Switched circuits are turned off when the bike is shut down. An un-switched circuit is always hot - can be used for charging the battery
- 8 ground outputs - much better to ground your auxiliary circuits here than on a bike’s frame
- maximum fuse panel capacity 40 Amps
- 30 Amp max switched. 20A max un-switched ( combination must be under 40 Amp total )
- maximum output circuit capacity 15A continuous
- maximum output wire size 12 AWG (3 sqmm)
- Spare fuse holder inside the PC-8R case ( can be use to hold 2 spare fuses )
- all hardware is stainless steel (except input posts which are tin plated steel)
- black satin polycarbonate cover makes unit splash-proof yet allows it to breathe and stay cool
- cover mounting tabs on each end can be broken off or left on, depending on mounting choice
- simple robust design means no overheating and no problems with vibration
KTM Adventure 1290 PC-8R Kit
( Includes the power wiring harness, switching lead, spare fuses, cable ties and standard velcro )
Note: If you would like to order a PowerLink version, just send us an email before ordering ( jim1 (at) easternbeaver (dot) com )
Note: If you would like to order a PowerLink version, just send us an email before ordering ( jim1 (at) easternbeaver (dot) com )
Price range: $112.95 through $122.95
KTM Adventure 1290 Brake Light Modulator
Brake Light Modulator for the KTM Adventure 1290. Will also fit other models that use the same tail light. Strobes the brake light 4 time when the brake light is applied.
Also includes a switched power break out cable. Can be used for accessory fuse box trigger in. Limit current to 1A max.
$49.95
