Description

Heated Grip Adapter

Connects to the factory heated grip connector using the connector above. Use for heated grips or other low current accessories. Also useful for relay switching. The stock heated grip connector on the bike has both a switched hot and a ground.

The stock heated grip connector supplies power to this adaptor only when the bike is on.

You can power and ground any low power accessory from this stock plug. However, it is not designed for higher current applications. I would suggest a maximum of 7A for this connector.

If you’re thinking to power a GPS from this connection, be aware that whenever you shut your bike off, power to your GPS will go off too. Many GPS have onboard battery power but it can still be tiresome every time you shut off to push a button on the GPS to get it to continue on battery power. I like my GPS powered full time with backlighting on high.

The Factory Heated Grip Connector – is found behind the left side of the radiator. Often the rad needs to be loosened on the left and moved forward to find the connector. See this page on Stromtroopers for pics to help locate your stock connector.

Specifications:

This adaptor features factory crimped terminals, high temp 16 AWG leads, and high temp sheathing.

Sumitube shrinktube sealed on the connector to keep out moisture and provide wire strain relief.

If you want to buy just the housing and terminals, buy the 2P-HM090 Male on this page.
